C3198 transistor technical information, including its features and specifications is available in this post.
Part Number: 2S3198
Function: 60V, 150mA, NPN Silicon Epitaxial Planar Transistor.
Package: TO-92 Type
Manufacturer: Elite, SEMTECH
Image :
Absolute Maximum Ratings (Ta = 25°C)
1. Collector to Base Voltage : Vcbo = 60 V
2. Collector to Emitter Voltage : Vceo = 50 V
3. Emitter to Base Voltage : Vebo = 5 V
4. Collector Current : Ic = 150 mA
5. Total Dissipation : Pc = 625 mW
6. Junction Temperature : Tj = 150°C
7. Storage Temperatue : Tsg = -55 ~ +150°C
Some text files in PDF file:
ST C3198 NPN Silicon Epitaxial Planar Transistor for switching and AF amplifier applications. The transistor is subdivided into four groups, O, Y, G and L, according to its DC current gain. On special request, these transistors can be manufactured in different pin configurations. TO-92 Plastic Package Weight approx. 0.19g Absolute Maximum Ratings (Ta = 25 ) Collector Base Voltage Collector Emitter Voltage Emitter Base Voltage Collector Current Base Current Power Dissipation Junction Temperature Storage Temperature Range Symbol VCBO VCEO VEBO IC IB Ptot Tj TS G S P FORM A IS AVAILABLE Value 60 50 5 150 50 500 125 -55 to +125 Unit V V V mA mA mW OC OC SEMTECH ELECTRONICS LTD. (Subsidiary of Semtech International Holdings Limited, a company listed on the Hong Kong Stock Exchange, Stock Code: 724) R Dated : 07/12/2002 ST 2SC3198 Characteristics at Tamb=25 OC DC Current Gain at VCE=6V, IC=2mA Current Gain Group O Y G L at VCE=6V, IC=150mA Collector Emitter Saturation Voltage at IC=100mA, IB=10mA Base Emitter Saturation Voltage at IC=100mA, IB=10mA Collector Cutoff Current at VCB=60V Emitter Cutoff Current at VEB=5V Transition Frequency at VCE=10V, IE=1mA Collector Output Capacitance at VCB=10V, f=1MHz Base Intrinsic Resistance at VCB=10V IC=1mA, f=30MHz Noise Figure at VCE=6V, IC=0.1Ma at f=1KHz, RG=10KΩ Symbol hFE hFE hFE hFE hFE VCE(sat) VBE(sat) ICBO IEBO fT COB Rbb’ NF Min. 70 120 200 350 25 80 – – G S P FORM A IS AVAILABLE Typ. 100 0.1 2 50 1 Max. 140 240 400 700 0.25 1 0.1 0.1 3.5 – 10 Unit V V µA µA MHz pF Ω dB SEMTECH ELECTRONICS LTD. (Subsidiary of Semtech International Holdings Limited, a company listed on the Hong Kong Stock Exchange, Stock Code: 724) R Dated : 07/12/2002 [ … ]
