The LM7805 is a fixed voltage regulator (IC) that converts an input voltage to a rated 5V output voltage. Provides stable 5V output under various voltage and current conditions.
Part number: LM7805CT, 7805
Package information: TO-220 Type
Functions: 3-Terminal 1A, 5V, Positive Voltage Regulator
Manufacturer: Fairchild Semiconductor ( onsemi.com )
Image:
Description
The LM7805 series of three-terminal positive regulators is available in the TO-220 package and with several fixed output voltages, making them useful in a wide range of applications.Each type employs internal current limiting, thermal shut down and safe operating area protection, making it essentially indestructible. If adequate heat sinking is provided, they can deliver over 1A output current. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain adjustable voltages and currents.
The LM7805 requires an input voltage of at least 7V and the output can supply up to 1A of current. This provides sufficient performance for use in most low-power electronic devices or circuits.
This device consists of three pins. It consists of an input pin (Vin), an output pin (Vout), and a ground pin. By connecting these pins appropriately, we can supply input voltage and get output voltage.
Pinout
Features
1. Output Current up to 1A
2. Output Voltages of 5V
3. Thermal Overload Protection
4. Short Circuit Protection
5. Output Transistor Safe Operating Area Protection
Block Diagram
Ordering Information
LM7805CT : 5 V
LM7806CT : 6 V
LM7808CT : 8 V
LM7809CT : 9 V
LM7810CT : 10 V
LM7812CT : 12 V
LM7815CT : 15 V
LM7818CT : 18 V
LM7824CT : 24 V
Other data sheets within the file : 7805, LM7808, LM7809, LM7810
Reference Site : https://en.wikipedia.org/wiki/78xx
Official Website : https://www.onsemi.com/
